ACOLAN COPPER
Applications
- 10 Gigabit high speed data transmission cables are designed for horizontal cable distribution local computer networks.
- These cables allow the use of the protocol supported by the F class for the 10 GBASE-T applications.
- They are characterized of up to 1000 MHz.
- They are compatibles with PoE & PoE+, UPoE & 4PPoE (PoE++) applications.
General characteristics
|
Solid annealed red copper wire, AWG 23 Foam skin Pe insulation Æ ≤ 1.40 mm |
|
Cable assembly in Twisted Pairs |
|
Pet/Alu foil around each pair |
|
4 pairs screening assembly |
|
Tinned copper braid |
|
LSOH-FR : Low Smoke « Zero » Halogen - Flame Retardant
|
|
LSOH-FR : Low Smoke « Zero » Halogen - Flame Retardant UV stabilisant for IN&OUT application |
|
Designation ACOLAN |
Ref. |
Colour |
Diameter |
Weight |
PCS (superior calorific capacity) |
Max. pulling tension |
|
|
mm |
Kg/km |
MJ/km |
KWh/m |
N |
|||
|
1000 SF-P 4P LSOH-FR / LSOH FR UV |
R7161A |
Black |
10.20 |
110 |
1474 |
0.409 |
95 |
|
Characteristics |
Values |
|
Tear strength of the sheath |
ISO 34-1 > 3 N/mm |
|
Tensile strength of the sheath |
IEC 60811-501 ≥ 8 N/mm² |
|
Elongation at break of the sheath |
IEC 60811-501 ≥ 100 % |
|
Characteristics |
Values |
|
|
Bending radius |
Dynamic (installation) |
≥90 mm |
|
Static (installed) |
≥45 mm |
|
|
Temperature range |
In service |
- 40°C à + 80°C |
|
At the installation |
-10°C à + 50°C |
|
|
Transport and storage |
-40°C à + 80°C |
|
|
Characteristics |
Values |
||
|
Complete conductor resistance |
|
≤ 146.4 W / km |
|
|
Resistance unbalance |
|
≤ 2 % |
|
|
Dielectric strength |
Continuous current |
1kV during1 minute = No breakdown |
|
|
Insulation resistance |
(500 V) |
≥5000 MW . km |
|
|
Capacitance unbalance |
Real-ground |
≤ 1600 pF / km |
|
|
Characteristic impedance |
at 100 MHz |
100 ± 5 W |
|
|
Velocity |
nominal |
78 % |
|
|
Coupling attenuation |
|
≥85 dB |
TYPE 1 |
|
Transfer impedance |
At 1 MHz |
≤ 8 mW / m |
GRADE 1
|
|
At 10 MHz |
≤ 8 mW / m |
||
|
At 30 MHz |
≤ 10 mW / m |
||
|
At 100 MHz |
≤ 20 mW / m |
||
|
Segregation classification acc. To EN 50174-2 |
|
“d” |
|
Norms and standards
Application
IEEE 802.3 :10Base-T; 100Base-TX;1000Base-T; 2,5GBase-T ; 5GBase-T ; 10GBase –T
IEEE 802.3 af (PoE) / 802.3 at (PoE+) / 802.3 bt (4PPoE 90W)
IEEE 802.5 / FDDI / ATM / RNIS
Cable
IEC 61156-5 ed.2 / EN 50288-4-1
Cabling system standard
ISO/IEC 11801 2nd ed. / EN 50173-1
Cabling system installation standard
EN 50174
Directive / Regulation
RoHS 2011/65/UE
REACH 1907/2006/EC
Because of its application, this cable isn’t subjected to the construction products regulation.
|
No flame propagation |
IEC 60332-1 / EN 60332-1 |
|
No fire propagation |
IEC 60332-3-24 / EN 60332-3-24 |
|
Low smoke opacity |
IEC 61034-2 / EN 61034-2 Transmittance > 60% |
|
Low gas corrosivity |
IEC 60754-2 / EN 60754-2 pH > 4.3 Conductivity < 10µS/mm |
|
Low toxicity |
IEC 60754-1 / EN 60754-1 ITC ≤ 5 INC ≤ 100 |
EUROCLASS
Recommendations
|
Type |
References |
Individual |
Expedition |
||||
|
Type |
Weight |
EAN code |
Type |
Weight |
EAN code |
||
|
4P LSOH-FR |
R7161A - T1000 |
BC Drum of 1000 m |
124 kg |
3700223679485 |
1 drum |
133 kg |
3700223679485 |
