PHOTO PRODUIT ACOME B1104A

"ACOLAN OPTICAL - CLT REINFORCED PE "

Reference : B1104A
4xOM2 LOOSE OUTDOOR PE REINFORCED DIELECTRICAL - BLACK

Benefits

  • Flexible inner Tube
  • Cable with ripcord
  • Reinforced Protection against rodents
  • Optimal design to facilitate preparation and access to fibers

Applications

  • High-speed data transmission cables are designed for all applications (campus, backbone, horizontal cables)and available for all environments (Industrial, Residential and Office Buildings).
  • They can be use Outdoor.

General characteristics

COUPE

ACOME Protection Index against rodents IPA:   ✭✭✭✩✩= Protection Renforcée

Marking of outer jacket: ACOLAN CLT RFD PE - fiber count & type - product reference – DD/MM/YY hh:mm + metric





GENERAL

Characteristics

Value

Z1325A

4 to 12FO

Temperature range

Transport and storage

- 40°C at + 70°C

At the installation

-5°C at + 50°C

In service

-20°C at + 60°C

Maximum pulling force (N)

3000

Crush resistance (N/cm)

400

Minimum bending radius (mm)

10xD

Standard packaging

2100m drums

Nominal sheath thickness (mm)

1,2

Nominal diameter (mm)

8

Nominal weight (kg/km)

61

Wrapping: cables are supplied with a protective wrap which must be maintained until full use of the product.

COLOR CODE

FOTAG

Range

Cable Content Multimode 50/125 OM2 ACMM50  Multimode 50/125 OM3 ACMM50  Multimode 50/125 OM4 ACMM50  Monomode 9/125* OS2 ACSM2-D METRO
4 fibers B1104A B1112A B1120A B1128A
6 fibers B1105A B1113A B1121A B1129A
8 fibers B1106A B1114A B1122A B1130A
12 fibers B1107A B1115A B1123A B1131A

 *9/125 : fibres UIT-T G.652.D



Norms and standards

GENERAL

logos cables de france        logo reach        logo ce



STANDARDS
Cable et fibers : EN 60793 / EN 60794-1
Wiring systems : EN 50173-1 / ISO 11801
Applications : IEEE 802.3 10M to 10Gbit  / IEEE 802.5 Token ring  ANSI X3T9-5 (FDDI) ATM (155, 622, …)
