R8550A-ST1000 | ACOLAN® COPPER FIREPROTECT

Reference : R8550A-ST1000
U/UTP Cat.6 400 MHz 4P LSOH-FR DRUM 1000m- GREEN

Benefits

  • Improved Fire performance Euroclass Cca
  • Small diameter

Applications

  • High speed data transmission cables are designed for backbone distribution local computer networks.
  • These cables are permitted the protocol supported by the class E.
  • They are characterized of up to 400 MHz and are compatibles with PoE & PoE+, UPoE applications.

General characteristics

Characteristics_acome_acolan_copper

  1. Conductor

Solid annealed red copper wire, AWG 24
Colored polyethylene insulation Ø ≤ 1 mm



  1. Cable element

Cable assembly in Twisted Pairs

  1. Separator

Symetrical cross separator

  1. Cable assembly

4 pairs assembly

      5. External sheath

LSOH-FR: Low Smoke « Zero » Halogen - Flame Retardant

GENERAL

Designation

ACOLAN FIREPROTECT

Ref.

Colour

Diameter

Weight

Superior calorific capacity (PCS))

Max pulling tension

mm

Kg/km

MJ/km

KWh/m

N

 400 UU 4P LSOH-FR

R8550A-S

Green (RAL6024)

5.80

40

505

0.140

90

MECHANICAL

            Characteristics

Values

Bending radius

Dynamic (installation)

≥ 50 mm

Static (installed)

≥ 25 mm

Temperature range

In service

- 20°C at + 60°C

At the installation

0°C at + 50°C

Transport and storage

0°C at + 50°C



ELECTRICAL

Transmission characteristics at 20° C



Characteristics

Values

Complete conductor resistance



≤ 190 Ω / km

Resistance unbalance



≤ 2 %

Dielectric strength

Continuous current

1kV during1 minute = No breakdown

Insulation resistance

(500 V)

≥ 5000 MΩ . km

Capacitance unbalance

Real-ground

≤ 1600 pF / km

Characteristic impedance

à 100 MHz

100 ±  5 Ω

Velocity

nominal

66 %

Coupling attenuation



≥ 40 dB

TYPE 3

Segregation classification acc. EN 50174-2



“b”



Frequency
(MHz)
  4 10 20 62.5 100 250 300** 450**
   Attenuation (dB/100m) Typical value 3.8 6 8.5 15.4 19.8 32.8 34.5 42
Imposition (max)* 3.8 6 8.5 15.5 19.9 33 - -
Next (dB)  Typical value 69 63 59 51 48 42 41 38
Imposition (min)* 65.3 59.3 54.8 47.4 44.3 38.3 - -
ACR (dB) Typical value 65.3 57.2 50.6 36 28.8 10.5 6.5
Imposition (min)* 61.5 53.3 46.3 31.9 24.4 5.3   -
PS Next (dB) Typical value 66 60 56 48 45 39 38 35
Imposition (min)* 63.3 57.3 52.8 45.4 42.3 36.3 - -
ELFEXT (dB/100 m) Typical value 73 65 59 49 45 37 35 32
Imposition (min)* 58 50 44 34.1 30 22 - -
PS ELFEXT (dB/100 m) Typical value 70 62 56 46 42 34 32 29
Imposition (min)* 55 47 41 31.1 27 19 - -
Return Loss (dB) Typical value 27 27 27 25.8 25 22 22 21
Imposition (min)* 23 25 25 21.5 20.1 17.3 - -

* Category 6 according IEC 61156-5
** For information only

Norms and standards

GENERAL

     logo poe    logo ce

400 Mhz

Applications

  • IEEE 802.3 :10Base-T; 100Base-TX;1000Base-T; 2,5GBase-T
  • IEEE 802.3 af (PoE) / 802.3 at (PoE+)
  • IEEE 802.5 /  FDDI / ATM / RNIS

Cables

  • IEC 61156-5 ed.2 / EN 50288-6-1

Cabling system standard

  • ISO 11801 2nd ed. / EN 50173-1 / TIA-568.2-D

Cabling system installation standard

  •  EN 50174

Directive / Regulation

  • RoHS 2011/65/UE
  • REACH 1907/2006/EC
EUROCLASS

EUROCLASSE CCA S1A D1 A1



FIRE BEHAVIOUR

Europe

Type

Euroclass

Standards

Declaration of performance

4P

Cca-s1a,d1,a1

IEC 60332-1, EN 50399,

 IEC 60754-2

19UUTP011

Zone de Texte: www.acome.fr

Outside Europe

No flame propagation

IEC 60332-1 / EN 60332-1

Low smoke opacity

IEC 61034-2 / EN 61034-2

Low gas corrosivity

IEC 60754-2 / EN 60754-2

Low toxicity

IEC 60754-1 / EN 60754-1



Recommendations

DELIVERY LENGTH

Type

References

Individual

Expedition

Type

Weight

EAN code

Quantity

Weight

EAN code

4P LSOH-FR

R8550A - SB305

RiB of 305 m

15 kg

3700223638796

18 boxes

292 kg

3700223638802

R8550A – ST500 Drum of 500 m 22 kg 3700223638819 18 drums 418 kg 3700223638826
R8550A – ST1000 Drum of 1000 m 43 kg 3700223639144 12 drums 538 kg 3700223639151
