R8600A
ACOLAN COPPER
Benefits
- Indoor/outdoor use
- 10 Gb/s
- Compatible with direct attach plug RJ45
Ideal for connecting terminals (cameras, ...)
Applications
- 10 Gigabit High speed data transmission cables are designed for backbone distribution local computer networks.
- Protected by a black UV resistant LSOH-FR sheath for outdoor use.
- Maximum length cable recommended : 70 m.
- These cables allow the use of the protocol supported by the F class for the 10 GBASE-T applications.
- They are characterized of up to 1000 MHz.
- They are compatibles with PoE & PoE+, UPoE & 4PPoE (PoE++) applications.
General characteristics
|
1. Conductor |
Solid annealed red copper wire, AWG 26 Foam skin Pe insulation Æ ≤ 1.00 mm |
|
2. Cable element |
Cable assembly in Twisted Pairs |
|
3. Pair screening |
Pet/Alu foil around each pair |
|
4. Stranding |
4 pairs screening assembly |
|
5. Screen |
Tinned copper braid and drain wire AWG26 tinned |
| 6. External sheath | LSOH-FR: Low Smoke « Zero » Halogen – Flame Retardant and UV resistant |
|
Designation ACOLANâ |
Ref. |
Colour |
Diameter |
Weight |
Superior calorific capacity (PCS) |
Max pulling tension |
|
|
mm |
Kg/km |
MJ/km |
KWh/m |
N |
|||
|
1000 SF-S 4P LSOH-FR IN&OUT |
R8600A |
Black |
5.90 |
38 |
365 |
0.101 |
55 |
|
Characteristics |
Values |
|
|
Bending radius |
Dynamic (installation) |
≥ 45 mm |
|
Static (installed) |
≥ 25 mm |
|
|
Temperature range |
In service |
- 40°C at + 75°C |
|
At the installation |
- 20°C at + 60°C |
|
|
Transport and storage |
- 40°C at + 75°C |
|
| Waterproofness | IP67 | |
Electrical characteristics at 20°C (68°F)
|
Characteristics |
Values |
||
|
Complete conductor resistance |
|
≤ 250 W / km |
|
|
Resistance unbalance |
|
≤ 2 % |
|
|
Dielectric strength |
Continuous current |
1kV during1 minute = No breakdown |
|
|
Insulation resistance |
(500 V) |
≥ 5000 MW . km |
|
|
Capacitance unbalance |
Real-ground |
≤ 1600 pF / km |
|
|
Characteristic impedance |
at 100 MHz |
100 ± 5 W |
|
|
Velocity |
nominal |
78 % |
|
|
Coupling attenuation |
|
≥ 80 dB |
TYPE 1b |
| Transfer impedance | At 1 MHz | ≤ 10 mW / m | GRADE 1 |
| At 10 MHz | ≤ 10 mW / m | ||
| At 30 MHz | ≤ 20 mW / m | ||
| At 100 MHz | ≤ 30 mW / m | ||
|
Segregation classification acc.to En 50174.2 |
|
‘’d’’ |
|
Norms and standards
Applications
IEEE 802.3 :10Base-T; 100Base-TX;1000Base-T; 2,5GBase-T ;
5GBase-T ; 10GBase –T
IEEE 802.3 af (PoE) / 802.3 at (PoE+) / 802.3 bt (4PPoE 90W)
IEEE 802.5 / FDDI / ATM / RNIS
Cables
IEC 61156-5 ed.2 / EN 50288-4-1 *
Cabling system standard
ISO/IEC 11801 2nd ed. / EN 50173-1 / EN 50173-5
Cabling system installation standards
EN 50174
Directive / Regulation
RoHS 2011/65/UE
REACH 1907/2006/EC
Europe
|
Type |
Euroclass |
Standards |
Declaration of performance |
|
|
4P |
EDca-s2,d2,a1ca |
IEC 60332-1, EN 50399, IEC 60754-2 |
22SFTP024 |
|
Outside Europe
|
No flame propagation |
IEC 60332-1 / EN 60332-1 |
|
Low smoke opacity |
IEC 61034-2 / EN 61034-2 |
|
Low gas corrosivity |
IEC 60754-2 / EN 60754-2 |
Recommendations
| Type |
References |
Individual |
Expedition |
||||
|
Type |
Weight |
EAN code |
Quantity |
Weight |
EAN code |
||
| 4P LSOH-FR |
R8600A – T500 |
Drum KC of 500 m |
21 kg |
3700223649303 |
18 drums |
391 kg |
3700223649297 |
| R8600A - RB300 | Box of 300 m | 14 kg | 3700223647705 | 18 boxes | 264 kg | 3700223647699 | |
