Product
B1109A
ACOLAN OPTICAL - CLT REINFORCED PE
24xOM2 LOOSE OUTDOOR PE REINFORCED DIELECTRICAL - BLACK
Benefits
- Cable with ripcord
- Reinforced Protection against rodents
- Optimal design to facilitate preparation and access to fibers
Applications
- High speed data transmission cables are designed for all applications (campus, backbone, horizontal cables)and available for all environments (Industrial, Residential and Office Buildings).
- They can be use Outdoor
General characteristics
Marking of outer jacket: ACOLAN CLT RFD PE- fiber count & type - product reference – DD/MM/YY hh:mm + metric
GENERAL
|
Characteristics |
Value |
||
|
Z1326A |
Z1328A |
||
|
24FO (bi-tubes) |
48FO (quadri-tube) |
||
|
Temperature range |
Transport and storage |
- 40°C at + 70°C |
|
|
At the installation |
-5°C at + 50°C |
||
|
In service |
-20°C at + 60°C |
||
|
Maximum pulling force (N) |
4500 |
||
|
Crush resistance (N/cm) |
400 |
||
|
Minimum bending radius (mm) |
10xD |
||
|
Standard packaging |
2100m drums |
||
|
Nominal sheath thickness (mm) |
1,5 |
||
|
Nominal diameter (mm) |
10 |
11,2 |
|
|
Nominal weight (kg/km) |
84 |
101 |
|
COLOR CODE
Range
|
Cable Content |
Multimode 50/125 OM2 ACMM50 |
Multimode 50/125 OM3 ACMM50 |
Multimode 50/125 OM4 ACMM50 |
Single mode 9/125* OS2 ACSM2-D METRO |
|
24 fibers |
B1109A |
B1117A |
B1125A |
B1133A |
|
48 fibers |
B1111A |
B1119A |
B1127A |
B1135A |
*9/125 : fibres UIT-T G.652.D
Norms and standards
GENERAL
| STANDARDS | |
| Cable et fibers | : EN 60793 / EN 60794-1 |
| Wiring systems | : EN 50173-1 / ISO 11801 |
| Applications | : IEEE 802.3 10M to 10Gbit / IEEE 802.5 Token ring ANSI X3T9-5 (FDDI) ATM (155, 622, …) |
